      Feature
      K,J,T,Pt100,400W
      4-20mA,0-10V
      Analog output 4-20mA
      P,I,D control to relay output
      PID Control with Auto-tuning
      Free power supply 95V-245V
      Din Size:96(h)×48(w)×105(i)
      TC Measureing Range
      Sensor Measuring Resolution Accuracy
      K -50~1300 1 0.5%F.S3
      J -40~760 1 0.5%F.S3
      S 0~600 1 0.5%F.S3
      E -150~900 1 0.5%F.S3
      RTD Measureing Range
      Sensor Measuring Resolution Accuracy
      Pt100 -50~600 0.1 0.5%F.S3
      Cu500 -50.0~150 0.1 0.5%F.S3
      Cu100 -50.0~150 0.1 0.5%F.S3
      Analog Input
      Sensor Measuring Resolution Accuracy
      0-10V -1999~9999 由量程確定 0.5%F.S3
      4-20mA -1999~9999 由量程確定 0.5%F.S3
      Specification
      Input mode Single ended
      Conversion 2.5/S
      A/D 雙積分
      Display Red LED(0.39")
      control system 8bit micromomputer
      Operating Temp. 0-50
      Power supply 165V-245V (AC)
      Power consumption ≤4.5VA
      Dielectic Strength Ac 1500V 1min
      Insulation Res. DC 500V≥100MW
      Relay volume 250V/2A
      Copyright 2002-2003      Sichuan Ludao Electrical Equipment Co,.Ltd. Tel:0830-2573101 2573102 Fax:0830-2573102
